Product category / NTC Bare Chip & NTC Thermistor
Automotive Sensor NTC Thermistor
VT series Automotive Sensor NTC Thermistor has characteristics of great stability and good capability of heat cycle, etc., which can meet the needs of various vehicle temperature sensor.
- Tel +86-758-2661333
- Email sla@exsense.com.cn / mkb@exsense.com.cn
Product Features
Product Characteristics
Product Application
Product Features
- Fast response
- Long robust performance
- Epoxy resin coating
- Excellent aging stability
Product Characteristics
- Operating temperature range: -40~150℃
- High temperature resistance
Product Application
- Automotive Oil/Water Sensor
- Measuring Device in High Temperature Environment
- Intake Air Temperature Sensor
| VT | 2K051 | G | B | 80C | 3435 | B | -L25 | T | 5 | D3 | ||||||
| 353R5 | ||||||||||||||||
| 3V305 | ||||||||||||||||
| Product Code | Resistance Value R Test Temp.℃ | Tolerance | Temperature Gradient | Test Temperature | Beta | Test Temperature of Beta | Total Length | Lead Material | Bare Lead | Coating Head Dimension | ||||||
| Voltage
R Test Temp.℃ |
||||||||||||||||
| VT Series NTC Thermistor | 202 | 20×102Ω | F | ±1% | O | -0% | 25C | 25℃ | 3435 | A | 25℃/50℃ | L25: 25mm | T | Telfon | 5: 5mm | D5: 3mm |
| 103 | 10×103Ω | G | ±2% | A | -1% | 80C | 80℃ | B | 25℃/85℃ | P | PVC | |||||
| 203 | 20×103Ω | |||||||||||||||
| 104 | 10×104Ω | H | ±3% | B | -2% | 90C | 90℃ | 4100 | C | 25℃/100℃ | C | CP | ||||
| 473 | 47×103Ω | J | ±5% | C | -3% | 100C | 100℃ | D | 50℃/100℃ | E | Epoxy CP | |||||
