Product details
Product category / NTC Bare Chip & NTC Thermistor
Epoxy Resin Coating NTC Thermistor
LT series epoxy resin coating NTC thermistor has small head size and excellent sensitivity, which is suitable for making high-accuracy temperature sensor, intelligent PCB, etc.
Product Features
Product Characteristics
Product Application
Product Features
- High accuracy
- Excellent consistency
- Excellent thermal cycle endurance
- High cost performance
Product Characteristics
- Operating temperature range: -40~125℃
- High stability
Product Application
- Cold-chain Transportation
- Medical Devices
- Smart Home
| LT | 103 | F | 3435 | B | |||
| Product Code | Resistance Value R25℃ | Tolerance | Beta | Test Temperature of Beta | |||
| LT Series NTC Thermistor | 202 | 20×102Ω | D | ±0.5% | 3435 | A | 25℃/50℃ |
| 502 | 50×102Ω | F | ±1% | ||||
| 103 | 10×103Ω | G | ±2% | ||||
| 104 | 10×104Ω | H | ±3% | 4100 | B | 25℃/85℃ | |
| 473 | 47×103Ω | J | ±5% | ||||
| *Special Parameters could be customized | |||||||
