High Precision NTC Temperature Probes For Industrial Control
TS series NTC Temperature Probes can be supplied with various NTC thermistor to suit your application.The design is made from metal probe . They are widely used Industrial Control or other applications due to their high stability and wide operating range of -40°C/+125°C.
- Tel +86 13679565096
- Email sak@exsense.net/ saa@exsense.net
Product feature
Product characteristics
Product application
Product Drawing
Product feature
- Stable performance, high reliability
- Fast response
- Customized specification
- Easy to install
Product characteristics
- Response Time : ≤10S
- Dissipation factor : About 2.6mW/°C
- Rated Power :≤15mW
- Hi-pot test:AC 3000V 2mA 2s
- Operating temperature :-40°C~125°C
Product application
1.Industrial Control
2. Gas hot water boilers
3. Ventilator
4. Water Temperature or other applications etc.
Product Drawing
- Product Model：TS104F25C3950FAGI-ML45A
- Wire : AWG30
- Resistor resistance value: R25ºC: 10K ,B25/85ºC: 3435,3950 or different NTC R-T curve available
- Operating temperature range:-40℃～125℃
- All the materials comply with the RoHS requirement
| S | 104 |
|
F | 25C | 3950 | F | A | _ | M | L130 | A | |||||||
| ① | ② | ③ | ④ | ⑤ | ⑥ | ⑦ | ⑧ | ⑨ | ⑩ |
| ① | ② | ③ | ④ | ⑤ | ⑥ | |||||||||||
| Product Series Code | Resistance @25℃ | R25
Tolerance |
Test Temp. of Resistance | B-value | B-value Tolerance | |||||||||||
| TS | TS Series
Temperature sensor |
104 | 10×104Ω | F | ±1% | 25C | 25℃ | 3950 | B=3950K | F | ±1% | |||||
| ⑦ | ⑧ | ⑨ | ⑩ | |||||||||
| Test Temp. of B-value | Head Material | Length | Distinguishing Code | |||||||||
| A | 25/50℃ | M | Metal | L130 | 130mm | A | First | |||||
| Part No. | R25℃
(KΩ) |
B(K) | Rated power
@25℃ (mW) |
Dissipation factor(δ)
(mW/℃) |
Thermal time
constant (s) |
| 202F3600A | 2 | 3600 | 10-20 | 2-4 | 3-10 |
| 502F3470A | 5 | 3470 | |||
| 103F3435B | 10 | 3435 | |||
| 303F3936A | 30 | 3936 | |||
| 104F3950A | 100 | 3950 |
