Product details

Product category / NTC Temperature Sensor Probe

High Stability NTC Thermistor Sensor For Laser Space Part

OTS series NTC temperature sensors, thermistors can be used for office automation equipment, laser printers, copiers roller), temperature monitoring, the NTC temperature sensor has rapid response, high precision, high reliability, high temperature resistant characteristics. Five series are available:FH/ OS/OL/OH/OP

  1. Product Model: OTS-OH-C327JOEIT2
  2. Wire : UL1332 #22AWG
  3. Wire length:50-2000mm
  4. Resistor resistance value:R180=6.5KΩ±5% B25/85=3370K±3% B100/200=3538K±3%
  5. Operating temperature range:-20℃~230℃
  6. All the materials comply with the RoHS requirement
OTS   OH   E 482


Product Series Code Product Type Resistance & B-value   Length
OTS Office Temperature sensor OH  type E R200=3.7KΩ±5%  B(100/200)=5108K±3%

R100=3.3KΩ±5%  B(100/200)=4353K±3%

482 482mm
Part No. Electronic parameter Remark
OTS-OH-1 R180=6.5KQ±5% B25/85=3370K±3% B100/200=3538K±3%
OTS-OH-2 R200=4KQ±5% B25/85=4557K±3% B100/200=4875K±3%
OTS-OH-3 R200=3.7KQ±5% B25/85=4640K±3% B100/200=5108K±3%
OTS-OH-4 R200=1KQ±5% B25/85=4253K±3% B100/200=4535K±3%
OTS-OH-5 R100=3.3KQ±5% B25/85=3966K±3% B100/200=4353K±3%
OTS-OH-6 R180=5.92KQ±3%  B(100/200)=5088K±3%
