Product details
Product category / NTC Bare Chip & NTC Thermistor
Miniature Insulated Lead NTC Thermistor
IT series miniature insulated lead NTC thermistor has characteristics of high sensitivity, excellent stability, high accuracy, etc., which can be measured accurate data.
Product Features
Product Characteristics
Product Application
Product Features
- Fast response
- Excellent interchangeability
- Great consistency
- Long leads
Product Characteristics
- Operating temperature range: -40~125℃
- Small head dimension
Product Application
- Body Thermometer
- Battery Pack/Charger
- Security Device
| IT | 103 | F | 3435 | B | -L80 | |||
| Product Code | Resistance Value R25℃ | Tolerance | Beta | Test Temperature of Beta | Length | |||
| IT Series NTC Thermistor | 202 | 20×102Ω | D | ±0.5% | 3435 | A | 25℃/50℃ | L80: 80mm |
| 103 | 10×103Ω | F | ±1% | B | 25℃/85℃ | |||
| 203 | 20×103Ω | G | ±2% | C | 0℃/25℃ | |||
| 104 | 10×104Ω | H | ±3% | 4100 | D | 0℃/50℃ | ||
| 473 | 47×103Ω | J | ±5% | E | 0℃/100℃ | |||
| *Special Parameters could be customized | ||||||||
