Product category / NTC Bare Chip & NTC Thermistor
Non-insulated Lead Type NTC Thermistor
AT series non-insulated lead type NTC thermistor has excellent capability of thermal cycle endurance stability. It is suitable for the production of household appliance, computer motherboard, charger, air-conditioning equipment, etc.
company name test
- Tel 6259+6213
- Email jgjgj@gmail.com
Product Features
Product Characteristics
Product Application
Product Drawing
Product Features
- High accuracy
- Excellent consistency
- Excellent thermal cycle endurance
- High cost performance
Product Characteristics
- Operating temperature range: -40~125℃
- High stability
Product Application
- Household Appliance
- Automotive Electronics
- Temperature Sensor
Product Drawing
| AT | 103 | F | 3435 | B | |||
| Product Code | Resistance Value R25℃ | Tolerance | Beta | Test Temperature of Beta | |||
| AT Series NTC Thermistor | 202 | 20×102Ω | D | ±0.5% | 3435 | A | 25℃/50℃ |
| 103 | 10×103Ω | F | ±1% | ||||
| 203 | 20×103Ω | G | ±2% | ||||
| 104 | 10×104Ω | H | ±3% | 4100 | B | 25℃/85℃ | |
| 473 | 47×103Ω | J | ±5% | ||||
| *Special Parameters could be customized | |||||||
1. Epoxy resin encapsulation
2. Stable performance
3. Small size,short response time,high sensitivity
4. Good thermal cycle endurance
5. Cost-effective
6. Customized requirements are accepted
