Product details
Product category / NTC Bare Chip & NTC Thermistor
SMD Type NTC Thermistor
CT series SMD type NTC thermistor is leadless, which is suitable for high-density surface mount. Product size: 0201, 0402, 0603, etc.
XXXXXX department of company
- Tel 86-123-YYYXXXX
- Email yyyxxx@exsense.net
Product Features
Product Characteristics
Product Application
Product Features
- Miniaturization
- Fast response
- High accuracy
- High reliability
Product Characteristics
- Operating temperature range: -55~150℃
- meet the need of automatic assembly
Product Application
- Smart Wear
- Automotive electronics
- Mobile communication devices
| CT | 103 | F | 3435 | B | -06 | ||||
| Product Code | Resistance Value R25℃ | Tolerance | Beta | Test Temperature of Beta | Dimension | ||||
| CT Series NTC Thermistor | 202 | 20×102Ω | D | ±0.5% | 3435 | A | 25℃/50℃ | 02 | 0201 |
| 103 | 10×103Ω | F | ±1% | 04 | 0402 | ||||
| 203 | 20×103Ω | G | ±2% | 06 | 0603 | ||||
| 104 | 10×104Ω | H | ±3% | 4100 | B | 25℃/85℃ | 08 | 0805 | |
| 473 | 47×103Ω | J | ±5% | 12 | 1206 | ||||
| *Special Parameters could be customized | |||||||||
